Productdetails:
|
Product Name: | Elevator Gearless Traction Machine | Voltage: | 380V |
---|---|---|---|
Suspension: | 2:1 | Load: | 1000KG |
Weight: | 140kg | Max.Static Load: | 2100kg |
Applicable: | Elevator Equipment | Warranty time: | One Year |
Model: | Elevator Gearless Traction Machine | Product: | Lift gearless tractiemachine |
Type: | Elevator Gearless Traction Machine |
Elevator Gearless tractiemachine, nominaal koppel 164 Nm, kortgesloten koppel 180s/h, polen 16
Statische belasting: 2100kg
Belasting: 1000kg
Snelheid: tot 1 m/s
Schijf: 100 mm
Gewicht: 140 kg
Nominaal koppel
|
Kortgesloten koppel
|
Polen
|
Encoder
|
Nm | Nm | / | / |
164 S5-40%ED 180s/u |
300 | 16 | ERN1387 ECN1313 EI53C9.25 TS5213N2531 |
Rem | |||
EMFR DC110V/1.9A[2X200Nm] |
2:1 | Laden | O | Toonhoogte | Koppel | Stroom | RPM | freq. | Huidige 220V | Huidige 380V | |
kg | Mevr | mm | mm | Nm | kW | RPM | Hz | A | A | |
800 | 0,4 | 100 | 65 | 127 | 2.03 | 153 | 20.4 | 9.3 | 5.9 | |
0,5 | 100 | 65 | 127 | 2.54 | 191 | 25.5 | 14.7 | 7.4 | ||
1.0 | 100 | 65 | 127 | 5.08 | 382 | 50.9 | 19.3 | 9.3 | ||
1000 | 0,4 | 100 | 65 | 159 | 2.54 | 153 | 20.4 | 11.6 | 6.8 | |
0,5 | 100 | 65 | 159 | 3.17 | 191 | 25.5 | 18.4 | 9.2 | ||
1.0 | 100 | 65 | 159 | 6.35 uur | 382 | 50.9 | 24.3 | 11.6 |
